Where is the relay panel, 75-308GT4?

Log Out | Topics | Search Moderators | Edit Profile

Author Message Mitchell Le (Yelcab1) Member Username: Yelcab1 Post Number: 654 Registered: 11-2001 Posted on Monday, August 25, 2003 - 2:19 pm:    I have the WSM too. It was not obvious whether the relay panel was immediately under the glovebox, or behind a false panel at the footwell. Of course, the WSM says nothing. Since others have done this before, I thought i would ask. Barry Wolinsky (308gtb) Member Username: 308gtb Post Number: 633 Registered: 2-2002 Posted on Monday, August 25, 2003 - 1:39 pm:    This is from the workshop manual: '75 308 GT4 (Peter) Advanced Member Username: Peter Post Number: 3031 Registered: 12-2000 Posted on Monday, August 25, 2003 - 12:00 am:    Mitch, the relay board is located behind the vertical panel, in the passenger's side foot-well. The piece of carpet covering it has some snap-buttons securing it in place. Just pull it off and the panel is secured by four screws... Mitchell Le (Yelcab1) Member Username: Yelcab1 Post Number: 648 Registered: 11-2001 Posted on Sunday, August 24, 2003 - 1:02 pm:    Found the fuse panel but don't know where the relays are. My Right fan does not work and I need to look at the relay.
