| Author | Message | ||
| Alfredo (Wimeldo)
New member Username: Wimeldo Post Number: 45 Registered: 7-2003 |
I have already repaired it, the problem was a contact in a cable. The rev rcounters of the 328 is just as the one of alfa romeo 75. Greetings | ||
| David Mcguire (Matkat)
Junior Member Username: Matkat Post Number: 80 Registered: 3-2003 |
I had the same problem with my 328 last month,I replaced the tacho,can confirm that the price for the new one is �171 (plus tax) from ferrari u.k. best regards Dave McGuire | ||
| wimeldo (Wimeldo)
New member Username: Wimeldo Post Number: 34 Registered: 7-2003 |
The connection with the ECU is correct, I have disconnected and connected the plug, I will see rev counter. Thanks for the information. | ||
| Dave328GTB (Hardtop)
Member Username: Hardtop Post Number: 674 Registered: 1-2002 |
Wimeldo, The tachometric sensor is attached to the bell housing where it pick up signals from the flywheel. If this was bad, the car would not run or run very poorly. The tach is wired to the ecu which is in the rear trunk driver's side. Lift up the carpeted piece and unbolt the plate. Ecu is attached to underside of the plate. However, all the connections to the ecu are in one big plug. It is very doubtful the problem is here. You can be 99% sure that the problem is in the rev counter itself. In the states, there are a couple of places that rebuild them. (I had it done myself). I'm sure there must be somewhere in your country. Dave | ||
| wimeldo (Wimeldo)
New member Username: Wimeldo Post Number: 32 Registered: 7-2003 |
in the car, where is the tachometric sensor? and where is the connection "wire terminal #24" thank you very much.  | ||
| '75 308 GT4 (Peter)
Advanced Member Username: Peter Post Number: 3112 Registered: 12-2000 |
Wimeldo, I have heard of problems identical to this that occured with 328's here in North America. In some instances, it was due to a faulty Magnetti "Microplex" unit, or simply the connection (wire terminal #24. Look in your Owner's Manual, page 74). | ||
| dave handa (Davehanda)
Intermediate Member Username: Davehanda Post Number: 1876 Registered: 5-2001 |
Wimeldo, You can either replace the tach, or have it rebuilt. Replacements are available from Ferrari UK at a reasonable cost (around $300 last time I checked). You could find a speedometer repair shop, experienced in Veglia instrument repair, and have it fixed for probably half that amount. There is a circuit board on the back of the gauge that must be repaired (I believe some of the components on the board fail, and they replace them). Easy to take out the tach, and reinstall. I just went through this earlier this year. | ||
| Mike Charness (Mcharness)
Intermediate Member Username: Mcharness Post Number: 1022 Registered: 8-2002 |
Wimeldo, we WELCOME folks for whom English is a second language. I am sure you speak and write English much better than most of use could do so in your language of Spanish! | ||
| wimeldo (Wimeldo)
New member Username: Wimeldo Post Number: 30 Registered: 7-2003 |
I request to you excuse to me, Mitch. I hope to learn to write. The engine is ok. My 328 tachometer only reads 3000 RPMs when the engine is at any revs higher than 3000 RPMs. :-) I believe that it is a habitual problem in the 328 and for that reason I want to make sure if I need to change rev to counter or another piece, or simply is a bad connection. greetings. | ||
| Mitch Alsup (Mitch_alsup)
Intermediate Member Username: Mitch_alsup Post Number: 1089 Registered: 4-2002 |
I did not want to impunge your speaking or reading ability, and it was clear that you were not a native English speaking person. Sorry if I offended you. However, your question could be read: My engine stops accelerating at 3000 RPMs even though the gas is floored. {indicating an engine issue} or My 328 tachometer only reads 3000 RPMs when the engine is at any revs higher than 3000 RPMs. {indicating a tachometer issue} | ||
| wimeldo (Wimeldo)
New member Username: Wimeldo Post Number: 29 Registered: 7-2003 |
:-) this it is not a Literature forum. >>>A) can you restate the question? In English Sorry, I am Spanish. I do not write well English, I read it. I request to you that you try to understand to me. >>>B) can you speak in complete sentences? Iden >>>C) can you add more detail? I will try it: the rev counter, only indicates up to 3000 RPM. it is easy. thank you very much Dave, that electronicas pieces I must replace? Gracias. | ||
| Dave328GTB (Hardtop)
Member Username: Hardtop Post Number: 673 Registered: 1-2002 |
The tachs on V8 cars of the late 80's are prone to fail and read to low. It needs to be pulled out and the electronics inside replaced. Dave | ||
| Mitch Alsup (Mitch_alsup)
Intermediate Member Username: Mitch_alsup Post Number: 1081 Registered: 4-2002 |
A) can you restate the question? In English B) can you speak in complete sentences? C) can you add more detail? | ||
| wimeldo (Wimeldo)
New member Username: Wimeldo Post Number: 26 Registered: 7-2003 |
I have "gts turbo" (Just as 328), and my rev counter only mark to 3000 rpm, where it is the problem? greetings |
